LOUVRE vertical SLAT Screens & Fences - Sold per SQM - Fixed Louvres slats
- Availability: In Stock
- Product Code: Aluminium Screening
- $297.00
LOUVRE SCREENS and FENCES
Vertical Model
Direct from the Warehouse
10 Richards Rd Narangba 4504
(Across the highway from Costco)
THIS IS A DIY PRODUCT AND EASY TO FIT & INSTALL
How to Get Fast Prices
- SMS me your size to 0414237573
- Tell me what height and width of the panel
- Tell me colour of slats
- Keep max size under 2400mm
For example a typical 1265 wide x 1270 high louvre screen or fence with 24mm air flow gaps and built Horizontal slats and in Black would be $428. That works out at $297 per SQM.
We offer 100mm and 65mm Vertical louvre slats
We are DIY only and the pickup is from Narangba.
The 100mm SLAT COLOURS WE STOCK
- Merbau Woodgrain
- Dark Grey - Flat
- Satin Black
- Red Cedar Woodgrain
- Gloss White
- Gloss Shale Grey
- Gloss Cream
- Paperbark
The LOUVRE RAILS WE STOCK Gloss WhiteSatin BlackDark Grey
The 65mm SLAT COLOURS WE STOCK
- Dark Grey - Flat
- Satin Black
- Gloss White
You can build your louvre screens and fences between Aluminium posts or your own brick piers or other post material like timber or steel.
We carry 76x76mm or 100x100 Aluminium Posts here.
All our slats are a Heavy Duty 100mm High x 16mm or 65mm x 16mm Thick aluminium profile with 2 reinforcing ribs inside. It's powder coated so
will give you at least a decade of no paint or maintenance.
Our Louvre slat holders are a rigid extrusion with laser cut slat holes that
hold the slats on a fixed angle.
For 100mm louvres, the extrusion is 65mm wide (eg the width that goes on the top and bottom).
When slats are inserted it leaves a 10mm gap between slats but the airflow gap
is 24mm.
For 65mm louvres, the extrusion is 50mm wide (eg the width that goes on the top and bottom).
When slats are inserted it leaves a 10mm gap between slats and a 10mm airflow gap .
There is a 50x50 box frame around the entire panel so it is very self supporting
If the screen is taller than 1400mm then a 3rd louvre track will be provided for the centre, to support the slats.
So it's a sleek and strong finish where all slats slide into its housing.
The screws are external so when you fit, decide which side will see them.
The slat top and bottom holders and box channel only come in BLACK, DARK GREY & WHITE.
We cut orders on Tuesdays & Thursdays so get your order in before that & we
work till all jobs are out.
Your width won't normally divide equally so there are fixed widths you need
to work with. Eg 1600mm wide is fixed but you can go up or down in lots of
106.5mm (65.4mm for 65mm slats) to suit your job. If the width you provide doesn't suit a full vertical slat, we will build the frame leaving an even gap on the left and right.
Remember the HEIGHT size you give us, the louvre screen will be cut to
that size & we will do the allowances for the frame supplied around it.
We are a small family run Brisbane company but we fill all our orders each cut
day and we never leave anyone hanging. Our prices are transparent and the price
algorithm we use is a fair price for all for the fast service provide. I can
quote in 5 minutes so don't be afraid to ask for new sizes if needed.
My direct mobile is 0414237573 so feel free to switch to SMS which can be
faster.
If you need posts then it's $40 per metre cut to size. Posts are in Black or White, Dark Grey or Merbau alloy. All 76x76mm strong aluminium posts that are matching colours.
We don't do any home Installing or site visits at all. We are just DIY.
This means it's all cut to your sizes & all the screws included. We don't
provide screws to fit to your structure.
All you need at home is a tek drill and a bit of time.
SIMPLE TO USE INSTRUCTIONS BELOW – All fittings generally in stock
- Most people will build the louvre screens as panels on the ground before installing.
- Build the 50x50.box frame with the internal angles
- Connect the top and bottom rails with a slat by sliding it inside the laser cut holes. Remove the plastic from slats only for the section that will be inserted
- Insert first slat, get it level & Tec Screw it from the rear, then connect to other side channel and do a measure (screws are free)
- We have allowed a clearance of 4mm overall for the slat.
- Insert next slat, etc. letting the other end hang while lying ti down
- Once done, gently manipulate the other side channel into all the slats (this can be fiddly), then TEC if needed but most won't.
- Insert panel into your space and screw in from behind to keep the screws as invisible as possible
PRICES - Cut to size then you assemble at home
- Posts in Black are $40/lm cut to suit including the post cap
- See the widths that you need to use to make sure slats finish on a full slat. Heights whatever you like but widths to match below
WE ALSO MAKE STANDARD FLAT SLAT SCREENS AT AROUND $90 PER SQM CHEAPER
BULKY GOODS
DELIVERY
- If only buying 1 x gate
or 1 x panel then Australia wide wrapping and shipping is =$120.
- If buying more, then see
the flat rate shipping Info below:
-$140 flat rate fee to the
Northside of Brisbane
-$200 flat rate fee to the
Southside of Brisbane
-$250 flat rate fee to the
Gold Coast, Ipswich or Sunshine Coast
-$350 flat rate fee to
Sydney or Rockhampton
-$450 flat rate fee to
Melbourne or Townsville
**We use backload trucks
for most of the above and usually do all drops in other country towns we pass
but following that main highway. Sometimes these deliveries will be after
hours
-All
other areas we can quote to a home in your state or country town
